| H.264&H.265 Full color visible light warning Tracking function warning PTZ Camera | ||
| Technical | ||
| Camera: 1.Intelligent analysis + Active defense + AutoTracking + Star Light illumination 2.1/2.8" 2.0MPixel Sony CMOS IMX327, the higher sensitivity and latitude, the perfect image. 3.30X optical zoom, 4.7- 141mm 4.14PCS Warm light LEDS,Illuminating distance100m Dome Features: 1.Intrusion detection based on AI intelligent analysis. Supports a variety of behavior detection such as Tripwire, Intrusion, crossing fence, and fast moving. Support multiple trigger rules and linkage actions. 2.Support auto tracking function, after finding the target that meets the intrusion rule, the dome will immediately rotate the target-centered position to zoom in and track the target motion. 3.Support active defense intrusion function: after the target is found, the dome automatically turns to the target position, flashing the visible light (warm light dome), and the audio output line drives the live speaker to send out the voice. 4Support Audio I/O 5.Support POE (Optional) 6.Support Alarm I/O (Optional) 7.Support CVBS out (Optional) | ||
| Form parameters | ||
| Mode | Name and Description | H.264&H.265 Full color visible light warning Tracking function warning PTZ Camera |
| ASRIH699A-030-5525 | ||
| Camera | Image Sensor | 1/2.8" 2.0MPixel Sony CMOS IMX327 |
| Effective Pixels | 2.0 Mpixes | |
| Min. Illumination | Color:0.02Lux@(F1.6, AGC ON) B/W: 0.002Lux@(F1.6, AGC ON) | |
| Zoom | 30X , f=4.7- 141mm | |
| Day/Night | Day / Night / External control(IR Cut Filter) | |
| WDR | Digital WDR | |
| AGC | Auto / Manual | |
| Backlight | OFF / BLC / HLC / WDR | |
| Digital noise Reduction | 2DNR,3DNR | |
| Shutter speed | 1/2 - 1/30,000s, Auto | |
| Network | Video Compression | H.265 / H.264B / H.264H / MJPEG |
| Streams | Dual streams | |
| Frame Rate | Main stream: | |
| 1920*1080 / 1280*720, 1-25(30)fps | ||
| Sub-stream: | ||
| 704*576 / 480*640, 1-25(30)fps | ||
| MJPEG: | ||
| 1920*1080 | ||
| Bitrate | CBR/VBR, bitrate:1792Kbps~8192Kbps variable, 256Kbps~2104Kbps | |
| Audio Compression | G711A, G711Mu, G.726, AAC, MPEG2-Layer2, G.722.1, G.729 | |
| P2P | N/A | |
| Protocols | HTTP ,FTP,SMTP,UPnP,SNMP, DDNS,NTP,RTSP,RTP,TCP,DHCP, PPPoE | |
| Motion detect | Support | |
| Privacy Zone Masking | Support | |
| Onvif | Onvif 2.4 | |
| Network | 10/100M Base-TX Ethernet, RJ45 Connector | |
| Mini SD Card | Support 128G SD card max | |
| IR Parameters | Luminary | 14PCS Warm light LEDS |
| Night vision distance | 100M | |
| Lamp control | Auto, Manual, by Zoom | |
| PTZ | Pan Range | 360° continued rotation |
| Tilt Range | -10~90° | |
| Manual pan speed | 0.05~240º/S | |
| Manual tilt speed | 0.05~180°/S | |
| Preset points | 256 | |
| Cruise | 4 | |
| L/R Scan | 1 | |
| Horizontal Scan | 1 | |
| Power off memory | Support | |
| PARK Action | Home position/ Area Scan /Horizontal 360°scan/ Cruise | |
| General | Power | DC12V±10%, 4A / POE(Optional) |
| Consumption | <22W | |
| Work temperature | External-20ºC~60ºC | |
| Work Humidity | 0%~90% (Non condensing) | |
| Protection level | IP66 waterproof,4000V lightning protection | |
| G.W | 5.5kg | |
